Started in 1988, Mud Logging Engineering is a national scientific and technological journal approved by the General Administration of Press and Publication and the Ministry of Science and Technology of the People's Republic of China. Approved in 2004 (Approval Number 1371 ), the journal is publicly distributed at home and abroad. The CN Serial Numbering is CN12-1371/TE, and the International Standard Serial Number is ISSN1672-9803. It is the only technical application-oriented journal reporting on oil and gas mud logging in China. Currently, it is a quarterly Chinese journal and a first-class journal in Tianjin....More
Current Issue
25 September 2026, Volume 37 Issue 3

  • Select all
    |
    DIGITAL INTELLIGENCE APPLICATION
  • Wang Zhi, Sun Hehui, Han Da, Zheng Hongwei, Song Changhong, Wang Ying
    Abstract ( ) Download PDF ( ) HTML   Knowledge map   Save
    To address the issues of delayed detection and passive response to kick and lost circulation during drilling operations,a full-process active defense monitoring system was designed and constructed based on the field applications of BH-EKLD early kick and lost circulation monitoring instrument. The system features high-precision measurement of diversion pipe micro-flow as its front-end sensing,combining with a flow rate increment early warning model based on physical process and operating condition coupling,along with closed-loop verification for automatic grouting control. By proposing a unified technical framework,signal processing,and anomaly identification process,establish a kick and lost circulation volume estimation model. Adopt anti-jamming filter and multi-parameter fusion decision methods to achieve a "monitoring-diagnosis-early warning-control" closed loop. Conduct statistical analysis on the field application data and demonstrate typical cases from 25 wells in multiple oilfields. The results show that the system advances the kick and lost circulation warning by an average of 3-5 min,with the minimum detectable flow rate change is less than 1 L/s,significantly improving the timeliness and success rate of well control disposal,and has engineering promotion value.
  • Chen Yongliang, Fu Bairu, Liu Fangyi, Song Tao, Hu Dan, Zhang Ze
    Abstract ( ) Download PDF ( ) HTML   Knowledge map   Save
    Monitoring of the liquid level in the circulating tank of drilling fluid is a core link for metering drilling fluid volume in mud logging engineering,as its monitoring accuracy directly determines the precision of total pit volume calculation and the reliability of well control warnings. Ultrasonic sensors are widely used for continuous liquid level acquisition in single tanks due to their non-contact and real-time characteristics. However,due to the influence of various complex factors such as the disturbance from the stirrer inside the tank,the impact of the return of drilling fluid,and the escape of bubbles,the liquid level often experiences irregular instantaneous fluctuations,resulting in significant deviations in the acquisition data and prone to triggering false alarms for total pit volume abnormalities. To address this issue,this paper proposes an error correction method based on extremum feature constraints. Firstly,use an extremum recognition algorithm to locate the local wave peaks and wave troughs of the liquid level curve,and extract four core features:fluctuation amplitude,duration,baseline offset,and relative amplitude. Secondly,combine mud logging business rules to set multi-dimensional constraining conditions,accurately distinguishing between irregular fluctuation errors and real liquid level changes. Finally,a steady-state baseline weighted fitting strategy is adopted to smooth and correct the fluctuating interval data. Completely keep the real trend of the liquid level changes while eliminating acquisition errors. After verification with data from multiple wells on site,the accuracy of this method in correcting liquid level irregular fluctuation errors in the circulating tanks can reach 91%. It effectively enhances the reliability of total pit volume metering data and can be directly applied to business scenarios such as mud logging well control intelligent early warning.
  • Tang Cheng, Shi Qiang, Liang Bo, Zhang Zhiping, Pu Wantong, Liu Weihua
    Abstract ( ) Download PDF ( ) HTML   Knowledge map   Save
    Conventional post-stack seismic inversion is highly dependent on drilling data. In areas with sparse wells and thin reservoirs featuring strong heterogeneity,it suffers from insufficient resolution and fails to accurately characterize the spatial distribution of reservoirs,which weakens its guiding value for geosteering. To improve the characterization accuracy of thin reservoirs in sparsely drilled work areas,a nonlinear neural network inversion method is adopted on the basis of comprehensive geological research of well blocks. This method establishes nonlinear correlations between target logs (including natural gamma ray,acoustic impedance,sensitive elements,etc.) and multi-seismic attributes. The established correlations are further extended to the entire seismic survey area to generate corresponding seismic attribute volumes. Comparative analysis with model-based acoustic impedance inversion results verifies that neural network inversion achieves superior performance in thin layer identification. Field applications demonstrate that reservoir characterization via neural network inversion delivers high resolution,and its delineation accuracy meets the requirements of geosteering while drilling for horizontal wells of thin reservoirs. This method provides significant guidance for real-time geological tracking and decision-making during drilling operations.
  • Guo Wei, Cheng Zaibin, Liu Shangrui, Dong Zhe, Wang Lingqiang, Song Yingjie
    Abstract ( ) Download PDF ( ) HTML   Knowledge map   Save
    Drilling torque is a key parameter characterizing drill string loading and downhole operating conditions. Owing to the coupled effects of multiple factors,drilling torque exhibits pronounced nonlinearity,time-varying behavior,and multiscale fluctuations,making it difficult for conventional models to simultaneously capture dynamic responses and maintain high prediction accuracy. To address this problem,a multi-step drilling torque forecasting method based on echo state network (ESN) is proposed. Weight on bit,rotary speed,standpipe pressure,and current torque are used as model inputs,and a direct multi-step forecasting strategy is adopted to generate predictions at steps of 1,5,10 and 30. The experimental results demonstrate that the ESN performs exceptionally well in short-term forecasting. For the 1-step prediction,the coefficient of determination R2 reaches 0.987 6,with a root mean square error of 0.181 4. The R2 value is 0.757 7 for the 5-step prediction,whereas it decreases to 0.560 1 and 0.515 8 for the 10-step and 30-step predictions,respectively. These results indicate that the drilling torque sequence is highly short-term prediction. However,as the prediction step size increases,high-frequency component prediction ability attenuates substantially,while low-frequency trends remain partially predictable. From an engineering perspective,at a sampling frequency of 1 Hz,a 5-step prediction provides a lead time of approximately 5 s,which is sufficient to support real-time early warning. Taking R2≥0.75 as the criterion for engineering applicability,the effective prediction temporal scale under the investigated operating conditions is approximately 1-5 s. This study provides technical support for real-time monitoring and abnormal-condition early warning during drilling operations.
  • Wang Yelei, Du Huanfu, Xi Xili, Zhang Hongxue, Yao Mengmeng, Wang Chunwei
    Abstract ( ) Download PDF ( ) HTML   Knowledge map   Save
    Regarding the difficulty of calculating the mineral concentration of volcanic rocks in Huoshiling Formation,Chaganhua area of Changling fault depression in Songliao Basin,this paper explores methods to efficiently calculate the mineral concentration using element logging data. Based on rock cuttings and core samples of cored wells from Huoshiling Formation in the study area, obtain element logging data and X-ray diffraction (XRD) mineral analysis data. The true values of mineral concentration in core and rock cuttings samples are calibrated by using core scanning photographs,thin section identification and RoqSCAN mineral automatic analysis technology. After preprocessing the data,five machine learning algorithms of ridge regression,random forest,extreme gradient boosting(XGBoost),light gradient boosting machine(LightGBM),and neural network are used to carry out training and assessment. This study indicates that Al,Ca,Fe,K,Mg,Mn,Na and Si are the key modeling elements of the mineral calculation model. Except for neural network,the other four algorithms perform well in the calculation of major petrogenetic minerals,with R2 generally higher than 0.9 and root mean square error(RMSE) lower. Calcite,soda feldspar,quartz,potash feldspar and illite have achieved relatively good calculation results overall,among them soda feldspar and quartz have the highest calculation accuracy. This mineral concentration calculation method provides technical support for quickly obtaining the volcanic rock mineral concentration based on element logging and reservoir evaluation.
  • Song Minghui, Ye Qing, Zong Xiyu, Zhang Shuo, Wang Yu, Wang Wei
    Abstract ( ) Download PDF ( ) HTML   Knowledge map   Save
    Online imaging of rock cuttings is the core process of automated mud logging,and image sharpness directly determines the accuracy of lithology identification and oil-bearing property analysis. When using the traditional hill climbing for on-site rock cuttings acquisition,the lens often experiences focusing reciprocating movement and cannot lock onto the optimal focus plane,this frequently leads to defocusing,rendering it inadequate for meeting the demands of on-site high-definition imaging. For the characteristics of operating conditions at mud logging sites,where there are large differences in rock cuttings particle size,narrow imaging depth of field,and continuous vibration of the equipment,an improved hill climbing automatic focusing algorithm is proposed. First,an adaptive window is used to screen the effective imaging region of rock cuttings for sharpness evaluation. Then dynamically adjust the lens search step size based on the level of blur in the images. Simultaneously optimize the image defocus judgment rules and gradient iterative logic,and reduce lens overshooting and reciprocating phenomenon. The comparative tests and field application results of multiple sets of rock cuttings imaging show that,compared to traditional algorithms,this solution reduces the number of focus travel steps by 25%-35% and shortens the single-focus operation time by 40%-45%. The deviation of the focusing position has been significantly narrowed,the success rate of stable focusing has increased to 98%,and the focusing positioning accuracy and dynamic response speed have both been significantly improved. This improved algorithm can effectively suppress back and forth focusing,shorten the search iteration process,and balance focusing accuracy and imaging response speed. It can adapt to the complex working environment of mud logging sites,providing stable and reliable algorithm support for online acquisition of high-definition images of rock cuttings and intelligent analysis of geological parameters.
  • EQUIPMENT R & D
  • Xiong Shichen, Liu Shining, Mo Guoyan, Chen Pei, Chen Guoping
    Abstract ( ) Download PDF ( ) HTML   Knowledge map   Save
    In geological mud logging exploration,the retrieval of complete and authentic cuttings is decisive for the accuracy of geological data. Addressed these issues of existing challenges in on-site cuttings retrieval,including low efficiency,poor sample representativeness,inadequate tool safety,and incompatibility with fast drilling operations,rock cuttings sampling tool was technically upgraded,and standardized sampling procedures were re-established. To meet the specific sampling requirements of offshore mud logging,a novel,differentiated dedicated rock cuttings sampling tool was developed through structural integration optimization and multifunctional module upgrades. This development was closely aligned with on-site field investigations,professional recommendations from sampling engineers,and industry operational manuals for rock cuttings sampling. Field applications across multiple wells in various blocks in the western South China Sea demonstrated significant improvements:the rock cuttings profile compliance rate (compared with well logging curves) increased from 85.5% using traditional methods to over 96.0%,while sampling time was reduced by nearly 30%. Furthermore,operator satisfaction with the tool reached 100%,as it substantially decreased labor intensity and markedly enhanced mud logging operational efficiency,successfully resolving critical pain points in offshore rock cuttings sampling.
  • TECHNOLOGY
  • She Mingjun, Li Youjian, Guo Yunfeng, Li Hongxin, Wang Xinling, Wang Yong
    Abstract ( ) Download PDF ( ) HTML   Knowledge map   Save
    In view of the technical bottlenecks of traditional formation drillability evaluation methods,such as lagging results,cumbersome sample preparation,long analysis cycles,and insufficient characterization by a single indicator,which make it difficult to meet the needs of real-time guidance for oil and gas drilling and efficient exploration and development of deep formations,based on laser-induced breakdown spectroscopy(LIBS) technology and its simultaneously generated plasma acoustic emission signals (PAES) technologies,the new technical ideas are proposed for integrated detection of the acoustic and optical information of rock cuttings excited by laser and multimodal fusion evaluation of formation drillability. By independently constructing an experimental platform for synchronous acquisition of rock cuttings sound and light,the comparative experiments were conducted on the harmonic acoustic waves,resonant acoustic waves,and acoustic-optical synchronous acquisition for multi-lithology rock cuttings samples. It was confirmed that there were significant differences in the spectral characteristics and acoustic wave characteristics of rock cuttings with different lithologies. Furthermore,spectral and acoustic wave information exhibited stable and regular correlations with lithological types,rock mechanics parameters,and formation drillability grades. On this basis,a dual-branch fundamental model comprising both an element information submodel and an acoustic wave information submodel was built. The deep integration of acoustic and optical characters was achieved through a deep learning fully connected network,forming an integrated model for predicting formation drillability. On-site rock cuttings and core samples from wells MB 1 and W 23C12-P2 were respectively selected for experimental verification and on-site application. The results indicated that the determination coefficient(R²) values of the model training set and test set as verified by the experiment reached 0.969 8 and 0.913 5 respectively. The longitudinal variation trend of formation drillability grades obtained using this acoustic-optical fusion evaluation method on site is consistent with the variation trend of logging evaluation results,with a determination coefficient(R²) reaching 0.863 7. Research and application results fully indicate that the laser-excited rock cuttings acoustic-optical fusion evaluation technology does not require complex sample pretreatment and the detection process is fast and non-destructive,can synchronously couple rock chemical composition with physical mechanics information,is capable of providing new high-precision mud logging technology support for drilling parameter real-time optimization,personalized drill bit lectotype,and safe downhole operations,and has the potential for promotion and application in deep oil and gas exploration and intelligent drilling engineering.
  • Mo Qianwen, Wang Ruifeng, Wang Zhenyan, Liu Hengyu, Yang Cong, Wang Xinhong
    Abstract ( ) Download PDF ( ) HTML   Knowledge map   Save
    In Sichuan Basin,both nonmarine clastic rocks and marine carbonate rocks are developed,making the formation pressure system complex. Existing the methods of pressure monitoring while drilling have poor applicability,and the traditional Eaton method relies on well logging interval transit time of finishing drilling, so it′s not real-time. Therefore,a study on the technology of cuttings acoustic formation pressure monitoring while drilling was carried out. Firstly,we investigated the geologic characteristics and overpressure mechanisms of Sichuan Basin,compared the calculation accuracy of the dc index method,Fillippone method,Bowers method,and Eaton method in nonmarine and marine strata,and determined Eaton method as the foundation model. Secondly,the BHDC cuttings acoustic mud logging unit was used to measure cuttings interval transit time while drilling,replacing well logging interval transit time. Using a moving average algorithm for noise reduction,we built a cuttings sonic trend line model,created a cuttings sonic-Eaton coupled pressure calculation model,and established a standardized process of monitoring while drilling.The method was applied on-site to 5 exploration wells in Sichuan Basin. Except for one well which had a large error due to water invasion disrupting the correlation between acoustic waves and effective stress,the error between the monitored pressure coefficient and the measured values in the other four wells was within 0.06. The overall accuracy rate was 80%. The results show that this method greatly reduces monitoring costs while ensuring accuracy,can meet the needs of the real-time warning while drilling,and provides an economical and effective technical approach for deep oil and gas exploration in Sichuan Basin.
  • Zhang Xuebin, Ma Fugang, Li Zhankui, Hua Caihong, Liu Chunxi
    Abstract ( ) Download PDF ( ) HTML   Knowledge map   Save
    To address the challenges of real-time formation profiling in the shallow Minghua Formation of the Bohai Oilfield under high-drilling-speed and high-inclination drilling conditions,such as data lag,cuttings distortion,and weak responses of engineering parameters,a dynamic closed-loop correction method combining well and seismic data is proposed. Prior to drilling,90° phase-shifted seismic data are used to construct a geological prior framework with lithological significance. During drilling,a model-guided dynamic sampling strategy is employed,integrating a delay time algorithm based on borehole diameter correction with lithofacies indices to achieve high-precision real-time lithofacies identification.Through real-time well-seismic correlation and a three-stage progressive correction process,the geological model is dynamically optimized. This method has been applied in 12 exploration wells in the Bohai Sea Oilfield. The results demonstrated that formation profile consistency improved from 74% to 92%,and profile update time was reduced from hours to minutes,which effectively addressed the challenges of real-time geological evaluation under complex conditions,providing reliable technical support for efficient shallow offshore exploration.
  • INTERPRETATION & EVALUATION
  • Sun Yepeng, Yao Zheng, He Chengshan, Huang Zijian, Fang Tieyuan, Zhang Liwei
    Abstract ( ) Download PDF ( ) HTML   Knowledge map   Save
    With the development of intelligent mud logging technology,element logging while drilling has become an important means to identify strata with complex lithologies. To meet the practical needs of lithology automatic identification,based on the data of element logging while drilling from Chang 7 Member,the Changqing Oilfield shale oil block,we established a multivariate linear regression relationship between elements and minerals through conjoint analysis of element logging and mineral logging. And by combining with machine learning to optimize key discriminant parameters,we built a multi-level crossplot chart identification system based on the fitted sandy content,shale content,and the contents of Fe,and S elements,and made a set of hierarchical,progressive rules for lithology automatic identification,enabling high-precision classification of six types of lithologies in the Ordos Basin′s Chang 7 Member:fine sandstone,carbonaceous mudstone,tuffaceous mudstone,silty mudstone,mudstone,and argillaceous siltstone. The application of this method to interpretation while drilling of Chang 7 main reservoirs shows that the accuracy of lithology naming has been improved to over 92%,which is significantly better than the traditional empirical discriminant method. The study results can serve as the core module of the intelligent mud logging interpretation system and have good replicability and promotion value.
  • Li Zhankui, Shang Suogui, Ma Fugang, Wen Haitao
    Abstract ( ) Download PDF ( ) HTML   Knowledge map   Save
    To address the challenges,such as the diversity of buried hill hydrocarbon reservoir types and their complex genesis in Bozhong Sag leading to contradictions between mud logging shows for actual drilling and testing results,as well as inaccurate identification of oil and gas properties,this paper proposes and defines gas logging parameter of C1maturity,establishes semi-quantitative evaluation criteria for reservoir oil and gas properties and identification standards for source rock grades,determines the oil and gas migration pattern through source-storage comparison,and combines with real-time carbon isotope logging charts,and identifies the genetic type and charging characteristics of natural gas,forming a "reservoir properties-migration pattern-genetic type-charging characteristics" technology chain of evaluation while drilling. This method has been applied to 10 buried hill wells in Bozhong Sag,with an accuracy rate of 80% in identifying oil and gas properties. It effectively determines the migration pattern,genetic type,and charging characteristics of oil and gas,avoids the ineffective testing of low-abundance primary migration reservoir-forming wells,and achieves the timely discovery of high gas-oil ratio condensate gas layers while drilling,which is helpful for guiding geologic comprehensive evaluation of problem wells.
  • Li Huaijun, Li Xiubin, Huang Weidong, Liu Huihui, Bian Gaofeng, Zhang Xiaohu
    Abstract ( ) Download PDF ( ) HTML   Knowledge map   Save
    In the exploration of low-rank bitumite in Junggar Basin,in view of the problems of strong subjectivity and poor timeliness of traditional coal rock quality evaluation methods,quantitative evaluation while drilling is explored by using element logging technology. Collect four types of samples:bright coal,semibright coal,semidull coal,and bleak coal. Through element logging analysis,sensitive elements Al+Fe,Si,and S are screened to reveal the quantitative relationship between the content of each element and coal rock quality,and a three-end-member evaluation model is constructed. A triangular chart with standardized interval [0,100] has been established.In the field application of three wells in Baijiahai area of Junggar Basin,the coal rock reservoirs for 16 intervals and 325 groups of samples were evaluated.Compared with microscopic observation results,289 groups of samples were consistent with the identification results,yielding a coincidence rate of 88.92%. Meanwhile,gas testing was conducted in well X 1,demonstrating a good correlation between coal rock quality and gas production rate. This method enables quantitative and visualized evaluation while drilling of the low-rank bitumite quality,providing technical support for the accurate evaluation of coalbed methane reservoirs in Junggar Basin.
  • Guo Yafei, Liang Zhiguo, Ni Youli, Zhou Changmin, Lyu Jiang, Yang Guang
    Abstract ( ) Download PDF ( ) HTML   Knowledge map   Save
    In view of the disconnection between on-site interpretation-while-drilling and laboratory experimental analysis,as well as the limitations of single evaluation method in current oil and gas mud logging evaluation,a fine evaluation method for reservoir fluid properties by integrating multiple parameters from on-site mud logging and laboratory experiments has been constructed. By systematically integrating on-site mud logging key parameters with laboratory experimental analysis indicators,adopting the grey relational analysis method to screen the sensitivity parameters that are highly related to oil testing production,then eliminating the redundant information,and using principal components analysis(PCA) to calculate the weight coefficients of each sensitive parameter,we separately built quantitative evaluation criteria for oil-bearing properties and aquosity. Ultimately,a two-dimensional comprehensive analysis is employed to achieve precise classification of reservoir types. The method was applied to 23 reservoir intervals of Yanchang Formation in Lingtai-Ningxian block of Yishan slope in Ordos Basin. The evaluation results show that the reservoir interpretation coincidence rate is 95.65%,significantly higher than on-site interpretation while drilling(72.9%) and conventional final interpretation(86.79%),enabling precise identification of complex reservoir types such as oil layers,poor oil layers,oil-water layers,water layers,and dry layers. The fine evaluation technology for the reservoir fluid properties has achieved an organic connection between on-site mud logging and laboratory experiments,effectively making up for the deficiencies of a single evaluation method. It significantly enhances the accuracy and efficiency of reservoir fluid properties evaluation,showing good engineering practicality and promotional value.It can provide reliable mud logging technical support for reservoir identification,reserve calculation,and development plan formulation.
  • Yang Guang, Nie Guimin, Zhao Liquan, Qin Fengqiang, Fu Kaiyue, Xu Shouhui
    Abstract ( ) Download PDF ( ) HTML   Knowledge map   Save
    The Kuihuadao structural belt in the eastern tidal zone of Liaohe Basin is a key zone for expanding reserves at scale. But the study on the origin and source of oil and gas in this zone remains relatively limited and the hydrocarbon generation capacity,as well as the oil and gas migration,accumulation,and distribution pattern for the main source sub-sags,are still unclear. Therefore,by utilizing the data of carbon isotope detection while drilling and combining with the carbon isotope fractionation effect,the studies were conducted on aspects such as the origin of oil and gas,the sources of oil and gas,and accumulation patterns. The results show that,the Kuihuadao structural belt has diverse types of oil and gas origin and complex sources of oil and gas. The bottom of the third Member of Dongying Formation is the early oil and gas charging,and later is invaded by high-maturity coal-type gas from the Gaizhou shoal sub-sag. The third Member of Shahejie Formation mainly consists of indigenous,high-maturity mixed organic matter generating hydrocarbons,characterized by autochthonous accumulation with lower source and upper reservoir. The natural gas of the upper Mesozoic gas originates from overmature coal-type gas sourced through lateral charging from the Gaizhou shoal sub-sag,while the bottom natural gas is mantle-sourced inorganic genetic gas. Based on this analysis,it is concluded that the oil and gas source for the Kuihuadao structural belt primarily derives from the source rock of the third Member of Shahejie Formation and the Gaizhou shoal source sub-sag in this locality. The accumulation patterns primarily involve lower source and upper reservoir,lateral deep charging and mixed-source accumulation.
  • Li Juan, Li Donglei, Zhang Junzi, Sun Jianghong, Chai Xiaowu, Wu Zhichao
    Abstract ( ) Download PDF ( ) HTML   Knowledge map   Save
    The Paleogene reservoirs in the inner Lixian Slope are generally poor in physical properties,leading to a low regional oil and gas drilling success rate and widespread disputes over its Paleogene exploration potential. Breaking exploration bottlenecks in reservoir-poor areas is critical to improving exploration quality and efficiency in this region. Based on fine seismic comprehensive interpretation technologies and historical drilling data,systematic old well re-evaluation was carried out to analyze regional structures,reservoir distribution and physical properties,and confirm favorable traps. A favorable structural trap of collapsed anticline was identified in the inner Lixian Slope. The main body of this collapsed anticline develops large-scale reservoirs with much better porosity and permeability than the low parts of surrounding anticlines,overturning the traditional understanding of universally poor reservoir properties in the study area. Vertically,seven sets of high-quality oil-bearing series were optimized from deep to shallow strata. A multi-layer collaborative hydrocarbon accumulation model for collapsed anticlines was established,and a series of integral traps were confirmed,with a total predicted oil and gas resource of 3 913×10⁴ t. The study achieves a record high in both the number of proven oil-bearing series and the continuous extension of oil-bearing intervals in the Lixian Slope. Reservoir-poor zones in the inner Lixian Slope have favorable hydrocarbon accumulation conditions and great exploration potential. The newly established multi-layer accumulation model of collapsed anticlines provides an important geological basis for subsequent exploration deployment,and opens up a new key exploration area in the inner Lixian Slope.
  • GEOLOGICAL RESEARCH
  • Zhang Shuangshuang, Yu Xiangdong, Wang Dan, Yu Chunyong, Li Zexi, Li Xin′ao
    Abstract ( ) Download PDF ( ) HTML   Knowledge map   Save
    Under the condition of multi-layer commingled production in tight sandstone gas reservoir producing wells,the lack of gas producing profile data results in unclear production contribution from each subzone and makes it difficult to quantitatively characterize the degree of interwell interference,hereby hindering the accurate evaluation of reserves producing degree. Taking X block of Sulige Gas Field as the study object,a production splitting model was established based on catastrophe theory using 9 parameters including open flow potential,gas layer thickness,porosity,permeability,and original gas saturation. The fine splitting of subzone production for multilayer commingled producing gas wells was finished. Combining with subzone production decline analysis,we can obtain the key parameters such as the producing reserves of each subzone,EUR(estimated ultimate reserve),and gas leakage range,create the congruent diagrams of the interwell leakage regions,and quantitatively evaluate the degree of interwell interference and interlayer producing differences in the study area. The study results are obtained in three aspects. First,the average relative error between the splitting results of the constructed catastrophe theory production splitting model and the measured data is 12.34%,with an error of 4.72% for the main layers. Second,for well X-8 in the study area,layer S12 is the main horizon,while layers H8X21 and H8X22 are secondary horizons. The producing degree and delivery of energy of the secondary layers are weaker than those of the main layers,and there is a significant difference in the interlayer production. Third,the southwest part of the study area has severe congruency of leakage regions and strong interwell interference. The central-northern and southeastern parts have lower well control,with some regions not fully put into production. The leakage range of horizontal wells is significantly better than that of vertical wells,and it causes more severe interference to adjacent vertical wells. Using the above method of the production splitting for multilayer commingled producing wells and interwell interference evaluation provides technical support for optimizing the well pattern of tight gas reservoirs,and has certain theoretical significance and field application value for the efficient development of similar gas reservoirs.
  • Li Dongqi
    Abstract ( ) Download PDF ( ) HTML   Knowledge map   Save
    Aiming at the key problems of low production in the structural highs and highly differential hydrocarbon distribution despite homologous structure and sedimentation in the XH 6-1X well block of Xinglong Structural Belt,Bayannur Sag,Linhe Depression,Hetao Basin,this paper adopts the research framework of "problem orientation-technical support-mechanism revelation -verification and application". Combined with multi-scale reservoir characterization and dynamic hydrocarbon accumulation simulation,the main controlling factors for differential hydrocarbon enrichment are clarified,and an identification model for hydrocarbon enrichment potential is established.The research conclusions are as follows:(1)The siliceous cementation intensity,reservoir property and hydrocarbon migration rate are the three core controlling factors for differences in hydrocarbon enrichment. The low production in structural highs is primarily caused by severe siliceous cementation that deteriorates reservoir physical properties. Additionally,the activity of secondary faults drives hydrocarbons to migrate toward structural lows.(2)Differences in hydrocarbon generation capacity of source rocks,reservoir porosity and cap rock sealing capacity between well XH 6-1X and well HT 101 further exacerbate the uneven distribution of hydrocarbons.Based on the identified main controlling factors,a triangular identification chart characterized by "siliceous cement content-reservoir porosity-hydrocarbon migration rate" is constructed to realize rapid evaluation of hydrocarbon enrichment potential. Meanwhile,two original exploration wells deployed in structural highs are relocated to favorable enrichment zones in structural lows,and horizontal wells are added. In view of the characteristics of low-porosity and low-permeability reservoirs,a regulation equation for drilling fluid density is established.Field application results show that the optimized well XH 6-3X reaches high-yield standards. The findings provide direct guidance for the efficient development of this wellblock,and also offer theoretical and technical references for hydrocarbon exploration and development in low-porosity and low-permeability blocks of Hetao Basin and similar fault-depressed basins.
  • Song Zhitong, Hu Guangwen, Hu Tao, , Li Honglin, Zhang Xiaowen, Chen Junpeng
    Abstract ( ) Download PDF ( ) HTML   Knowledge map   Save
    To tackle the problem of identifying the dominant lithologies of Carboniferous igneous reservoirs in JL 10 wellblock of Zhonguai uplift in Junggar Basin,due to their complex lithology and strong heterogeneity,by calibrating the core and thin section data,and using the difference between neutron porosity and density porosity as a parameter,the well log crossplot charts were established by using a "coarse to fine,step-by-step zoning" strategy,achieving fine identification of igneous rock lithology in the study area. It is found that andesite and volcanic breccia have obvious advantages in oil-bearing property,testing productivity,fracture development degree,and reservoir physical properties,making them identified as class I dominant lithology. By comprehensively analyzing well logging,seismic,and geologic data and adhering to the "facies-controlled modeling" principle,high-precision 3D structural models,lithofacies models,lithology models,and attribute models were constructed,clearly revealing the spatial distribution patterns of the dominant lithologies and achieving quantitative characterization of reservoir physical properties. Well Y 22 deployed under the guidance of this technical solution has a lithology coincidence rate of over 90% in actual drilling,providing important technical support for the prediction of dominant lithologies and highly efficient development of complex igneous reservoirs.
  • Yu Chunyong, Jia Yongsheng, Li Xiangkui, Yang Zhiguo, Tan Chao, Zheng Hongwei
    Abstract ( ) Download PDF ( ) HTML   Knowledge map   Save
    In Huachang area of Fushan Sag in Hainan Province,abnormal pressure has developed within the Liushagang Formation strata. Liushagang Formation,as the primary reservoir interval for hydrocarbon resources in the study area,has unclear genetic mechanisms for formation abnormal pressure and its vertical and lateral distribution regularities. To reveal the dynamic process of hydrocarbon formation and optimize the exploration deployment in this area,based on the measured formation pressure data,log and related geologic information,the genetic mechanisms of abnormal formation pressure in this area were deeply explored and its vertical and lateral distribution regularities were finely described. The results are obtained in four aspects. First, Liushagang Formation mainly develops weak low pressure-normal system,with only a certain degree of weak overpressure developed in the bottom parts of the first and third Members of Liushagang Formation. The formation pressure coefficient gradually increases from shallow to deep,with a distribution range of 0.6-1.54. The distribution range of formation pore fluid pressure is 12.66-52.15 MPa. Second,the distribution range of the overpressure depth is 3 000-3 875 m. Among them,the depth of the overpressure for the first Member of Liushagang Formation is about 3 000 m,and that for the third Member of Liushagang Formation is about 3 200 m. Third,the reservoir overpressure of Liushagang Formation has a good response relationship with the interval transit time,resistivity and density,characterized by high sonic transit time,low resistivity,and low density,which is a typical undercompaction-induced overpressure. The abnormally low pressure intervals are mainly related to their multiphase tectonic uplift and denudation. Fourth,on the plane,the pressure of the first Member of Liushagang Formation is high in the northwest and low in the southeast,while the pressure of the third Member of Liushagang Formation is high in the northeast and low in the southwest. Both have weak overpressure in some regions,and most regions are normal pressure or even abnormally low pressure. It is indicated that the abnormally low pressure formed by multiphase uplift and denudation makes the pore water in the reservoirs keep moving from sandstone to mudstone,which helps push water out of the hydrocarbon reservoirs. This eventually results in the low water-bearing hydrocarbon reservoirs that have relatively low water saturation but are enriched with oil and gas resources.The study results can provide a scientific basis for reference in the analysis of hydrocarbon accumulation and the optimization of exploration and development plans in the study area.
  • Xue Cheng, Dai Jianwen, Huang Yujin, Miao Yun, Yang Zhipeng, Deng Dafei
    Abstract ( ) Download PDF ( ) HTML   Knowledge map   Save
    A oilfield in Enping Sag of Pearl River Mouth Basin is characterized by distal delta front deposits,featuring thin reservoir thickness,high shale content,and strong reservoir heterogeneity,which makes detailed characterization of sedimentary microfacies extremely challenging. After years of development,the recovery factor of A oilfield has increased,while the natural decline rate has accelerated,necessitating urgent research on tapping the remaining oil potential.Taking the main oil-bearing intervals of the Miocene Hanjiang Formation in A oilfield as the research object,this study utilizes data from cores,well logging and 3D seismic surveys to summarize the characteristics of lithofacies and electrofacies. Various sedimentary microfacies are identified,including subaqueous distributary channels,mouth bars,distal bars,sheet sands,and subaqueous interdistributary bays. Single-well sedimentary microfacies analysis is conducted on cored wells to establish sedimentary microfacies framework profiles parallel and perpendicular to the sediment source direction. By integrating seismic attribute data and employing a well-seismic joint approach with stepwise constraints,the planar distribution characteristics of sedimentary microfacies in the main oil layers from H 2 to H 8 are meticulously depicted.The research results indicate that,from bottom to top,subaqueous distributary channel deposits are extensively developed in the H 8 sand body. Subsequently,during a rapid transgression,the subaqueous distributary channel deposits in the H 6 sand body gradually retreated toward the northwestern sediment source direction. This was followed by a sea-level drop and enhanced sediment supply,leading to the dominance of subaqueous distributary channel deposits in the H 5 sand body. Later,as sea level rose slowly,the subaqueous distributary channel and mouth bar deposits in the H 4-H 2 sand body progressively shrank toward the northwestern sediment source direction. The findings from the reservoir sedimentary microfacies study indicate favorable reservoir development areas,providing a basis for future detailed remaining oil potential tapping in the oilfield.
